Callbacks in Dash

Building Dashboards with Dash and Plotly

Alex Scriven

Data Scientist

What are callbacks?

Functionality triggered by interaction
- A user interacts with an element
  - -> A Python function is triggered
    - --> Something is changed
Why? Enhances interactivity

Callbacks in Dash

Start with the decorator function
- Uses from dash.dependencies import Input, Output
Output: Where to send the function return
- component_id: Identify the component
- component_property: What will be changed
Input: What triggers the callback
- component_property: What to use in triggered function

@app.callback(

   Output(component_id='my_plot',
          component_property='figure'),

   Input(component_id='my_input',
          component_property='value')

)

def some_function(data):
    # Subset Data
    # Recreate Figure
    return fig

Dropdowns in Dash

dcc.Dropdown(id='title_dd',
             options=[{'label':'Title 1',
                       'value':'Title 1'},
                      {'label':'Title 2',
                       'value':'Title 2'}]),

List of label-value dictionaries

A dropdown callback

app.layout = html.Div(children=[

  dcc.Dropdown(id='title_dd',
      options=[{'label':'Title 1',
                'value':'Title 1'},
               {'label':'Title 2',
                'value':'Title 2'}]),

  dcc.Graph(id='my_graph')])

@app.callback(
    Output(component_id='my_graph',
           component_property='figure'),

    Input(component_id='title_dd',
           component_property='value')
)

#@app.callback()
def update_plot(selection):
    title = "None Selected"
    if selection:
        title = selection

    bar_fig = px.bar(
      data_frame=ecom_sales,
      title=f'{title}',
      x='Total Sales ($)', y='Country')

  return bar_fig

Our first dropdown

A gif of a chrome web browser which has a bar chart of total sales (x-axis) and country (y-axis) with a dropdown above which has options of Title 1 and Title 2. The gif has the mouse select each of these, and the title in the graph changes to the associated dropdown value

Dropdown as a filter

Common use case - dropdown filters the plot DataFrame

#@app.callback()
def update_plot(input_country):
    country = 'All Countries'

    sales = ecom_sales.copy(deep=True)

    if input_country:
        country = input_country
        sales = sales[sales['Country'] == input_country]

    bar_fig = px.bar(
        data_frame=sales, title=f"Sales in {country}",
        x='Total Sales ($)', y='Country')
    return bar_fig

Let's practice!
